Portable Fiber Laser Marking Machine
MORN Portable Fiber Laser Marking Machine has an overall size as small as a desktop computer. The whole modular design makes it compact, light, and easy to carry in car or be transported by express courier. You could enjoy your marking time freely at the office, home, workshop, yards, craft shop, etc.
Features
https://youtu.be/LDe462w3aao
Overall modular design: compact, light, easy to carry freely;
Wide application: handle both metal and non-metal materials;
Standout performance: consistent marking quality with high speed(up to 7000mm/s), 2-3 times higher than traditional marking;
Long Lifetime: advanced laser generator, more than 100,000h;
Low consumption: electro-optic conversion rate up to 30%, power consumption lowered by 3-10 times compared with YAG laser;
Environment-friendly and energy-saving;
Product catalog? Price? More videos?
Welcome to contact us online or leave a message!
Parameters
| Laser Type | IPG/Raycus |
| Laser power | 20-100W |
| Max. Marking Speed | 7000mm/s |
| Graphics Format Supported | PLT,BMP,JPG,PNG,TIP,PCX,TGA,ICO,DXF, etc |
| Power Stability(8h) | <±1%RPM |
| Pulse Repeat Frequency | 20-100KHZ |
| Whole Machine Power | <800W |
| Mini Line Width | 0.01mm |
| Mini Character | 0.15mm |
| Laser Wavelength | 1064mm |
| Oscillating Mirror Area | 110*110/200*200mm (bigger size is optional) |
| Cooling Way | Air cooling |
| Working Voltage | 220V±10%/50HZ |
| Working Temperature | 5°C-35°C |
| Packing Weight | 160KG |
| Package Dimension | 970*810*1530mm |
| Package | Veneer case |
Laser Source
100,000 hours lifespan;
Excellent beam quality, high energy density, and reliability;
Especially suitable for fine marking.
上一页
下一页
MOPA Color Marking (Optional)
Color mark-able materials including: stainless steel
2D Work Table
Can be moved left and right;
Galvo lens
Equipped with automatic scanning system, friendely operation proccess;
7000mm/s marking speed, 0.001mm repeat precision.
Application
Applied Materials
Metal: gold, silver, copper, alloy, aluminum, steel, iron, stainless steel, etc.
Non-metal: ABS, Nylon, PES, PVC, Makrolon, etc.
Application Industries
| Auto Parts | car body, frame, chassis, girders, piston rings, shafts, bushes, clutches, lights, engines, connecting rods, cylinders, pistons, cylinder liners, gears, pumps, spring steel plates, etc. |
| Electronic Components | resistors, capacitors, chips, printed circuit boards, keyboards, etc |
| Mechanical parts | machine tools, hardware, steel pipes, casings, couplings, cones, pumps, body valves, flanges, fasteners; bearings, gears, standard parts, motor, etc |
| Instrumentation | panels, signs, precision instruments,etc |
| Hardware tools | measuring tools, locks, cutting tools, etc |
| Daily necessities | crafts, zippers, key chains, jewelry rings, sanitary ware, etc. |
